Properties and Applications
- Transparent, low-shrinkage casting with tack-free surfaces.
- Excellent flow properties due to its low viscosity.
- Cold-hardening and demouldable at room temperature, with the option to cure at slightly elevated temperatures.
- Highly fillable casting resin that forms pressure-resistant and impact-resistant molds or components with high strength and minimal shrinkage
Industrial and Hobby Applications
- Ideal for creating “River Tables” and other transparent, water-clear castings.
- Suitable for foundry patterns, die plates, reproduction patterns, and medium molds and castings.
- Can be used as an injection system for repairs and encapsulation of decorative elements.
- Functions as a leveling compound or injection resin for structural repairs.
Processing Data
| # | Characteristic | Value |
|---|---|---|
| 1 | Color | Colorless (resin), slightly yellowish (hardener) |
| 2 | Mixing Ratio | 100 parts resin : 50 parts hardener (by weight) |
| 3 | Viscosity (Mixed) | Low-viscosity |
| 4 | Working Time (Pot Life) | >60 minutes at 20°C |
| 5 | Demouldable Time | < 48 hours at 20°C, < 24 hours at 30°C |
| 6 | Full Cure | 7 days at 20°C |
| 7 | Working Temperature | 18-35°C |
Raw Material Data
| # | Characteristic | Value |
|---|---|---|
| 1 | Viscosity (Resin at 23°C) | 600 – 800 mPa·s |
| 2 | Viscosity (Hardener at 23°C) | 10 – 20 mPa·s |
Data of Unreinforced Resin
| # | Characteristic | Value |
|---|---|---|
| 1 | Density | 1.1 g/cm³ at 25°C |
| 2 | Hardness (Shore D): | 75 |
| 3 | Color (Mixed) | Transparent, colorless |
